Full Description

Sets out recommendations for the preparation of survey plans for engineering works and the illustration of proposed, designed and executed engineering works based on such survey plans. The first two sections, taken with Part 101 of AS 1100, provide a common language for the interdisciplinary communication of information by means of engineering survey and engineering survey design drawings. Section 3 provides symbols and abbreviations for use on special purpose drawings such as identification of details for a specific utility.

Product Details

Edition: 1st Published: 01/03/1984 ISBN(s): 0726231908 Number of Pages: 57 File Size: 1 file , 410 KB Product Code(s): 10116341, 10116330, 10116371
