Full Description

This Standard covers pressure-temperature ratings,materials, dimensions, tolerances, marking, testing,and methods of designating openings for pipeflanges and flanged fittings. Included are:flanges with rating class designations 150, 300,400, 600, 900, and 1500 in sizes NPS 1/2 through NPS 24and flanges with rating class designation 2500 in sizesNPS 1/2 through NPS 12, with requirements given in bothmetric and U.S. Customary units with diameter of boltsand flange bolt holes expressed in inch unitsflanged fittings with rating class designation150 and 300 in sizes NPS 1/2 through NPS 24, with requirementsgiven in both metric and U.S. Customary unitswith diameter of bolts and flange bolt holes expressedin inch unitsflanged fittings with rating class designation400, 600, 900, and 1500 in sizes NPS 1/2 through NPS 24and flanged fittings with rating class designation 2500in sizes 1/2 through NPS 12 that are acknowledged inNonmandatory Appendix E in which only U.S. Customaryunits are provided
This Standard is limited to:flanges and flanged fittings made from cast orforged materialsblind flanges and certain reducing flanges madefrom cast, forged, or plate materialsAlso included in this Standard are requirements andrecommendations regarding flange bolting, gaskets, andjoints.

Product Details

Published: 06/30/2009 ISBN(s): 9780791831991 ANSI: ANSI Approved Number of Pages: 238 File Size: 1 file , 4 MB Product Code(s): M1509Q, M1509Q, M1509Q
