ASTM A678/A678M-00a
ASTM A678/A678M-00a Standard Specification for Quenched-and-Tempered Carbon and High-Strength Low-Alloy Structural Steel Plates
standard by ASTM International, 09/10/2000
Full Description
1.1 This specification covers quenched-and-tempered carbon steel and high-strength low-alloy steel plates of structural quality for welded, riveted, or bolted construction.
1.2 When the steel is to be welded, it is presupposed that a welding procedure suitable for the grade of steel and intended use or service will be used.
1.3 Material under this specification is available in four grades as follows:
| Grade | YieldStrength,min, ksi[MPa] | Tensile Strength,ksi [MPa] | Maximum Thickness, in. [mm] |
| A | 50 [345] | 70-90 [485-620] | 11/2 [40] |
| B | 60 [415] | 80-100 [550-690] | 21/2 [65] |
| C | A | A | 2 [50] |
| D | 75 [515] | 90-110 [620-760] | 3 [75] |
1.4 The values stated in either inch-pound units or SI units are to be regarded as standard. Within the text, the SI units are shown in brackets. The values stated in each system are not exact equivalents. Therefore, each system must be used independently of the other. Combining values from the two systems may result in nonconformance with this specification.
