ASTM F2431-04(2018)
ASTM F2431-04(2018) Standard Specification for Ring Bearing, Inner: For Needle Roller Bearing with Thick Outer Ring
standard by ASTM International, 08/15/2018
Full Description
1.1This specification covers inner rings for needle roller bearings having thick outer rings.
1.2The inner rings being specified are intended for use on unhardened shafts in conjunction with the MS51961 needle roller bearings specified in Specification F2246.
1.2.1For needle roller bearings with thin outer rings (Specification F2162, MS17131, MS52141) use inner rings specified in Specification F2163.
1.3Inner rings designed to this specification are intended for use in applications requiring high radial load with minimal angular shaft misalignment.
1.4The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.5This specification contains many of the requirements of MS51962, which was originally developed by the Department of Defense and maintained by the Defense Supply Center in Richmond. The following government activity codes may be found in the Department of Defense, Standardization Directory SD-1.2
| Preparing activity | Custodians | Review Activity |
| DLA-GS4 | Army -AT | Air Force-84 |
| Navy-OS | ||
| Air Force--99 |
1.6This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
