ASTM D5321/D5321M-13

ASTM D5321/D5321M-13 Standard Test Method for Determining the Shear Strength of Soil-Geosynthetic and Geosynthetic-Geosynthetic Interfaces by Direct Shear

standard by ASTM International, 08/23/2013

More details

Reduced price!

M00074903

New product

Limited time offer:

$27.00

$60.00

-55%

In stock

- +

Add to compare

More info
Custom tab

More info

Full Description

1.1This test method covers a procedure for determining the shear resistance of a geosynthetic against soil, or a geosynthetic against another geosynthetic, under a constant rate of deformation.

1.1.1The test method is intended to indicate the performance of the selected specimen by attempting to model certain field conditions. Results obtained from this method may be limited in their applicability to the specific conditions considered in the testing.

1.2The test method is applicable for all geosynthetics, with the exception of geosynthetic clay liners (GCLs) which are addressed in Test Method D6243/D6243M.

1.3The test method is not suited for the development of exact stress-strain relationships for the test specimen due to the non-uniform distribution of shearing forces and displacement.

1.4The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance with the standard.

1.5This standard does not purport to address all the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety and health practices and determine the applicability of regulatory limitations prior to use.
