Full Description

1.1 This practice covers a standard symbol that may be used by the design-engineering community on engineering drawings to indicate a bonded assembly for any type of adhesive.

1.2 This design is based on criteria contained in ANSI/AWS A2.4 as well as ISO 15785.

1.3 The values given in SI units are to be regarded as the standard. The values in parentheses are for information only.

1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety and health practices and determine the applicability of regulatory limitations prior to use.
