Full Description

BS PD ISO/TS 13399-72:2016 defines the necessary text elements of a drawing frame and determinesa standardized data exchange format. Therefore, the effort is reduced for the maintenance ofdocumentation because the content of a drawing header is mated into a specific drawing frameby means of using XML technology and an individual mapping table. The benefit of this concept formanufacturer/supplier and end user is the advantage of a central maintenance of the appropriatetemplates.

This part of ISO/TS 13399 covers the following: identification and definition of the data fields; identification and definition of the structure of the data fields; structure of the data exchange file.The standardization of drawing formats, e.g. drawing frame, structure of the bill of material, are outsidethe scope of this part of ISO/TS 13399 which is rather more intended to standardize the data exchangeof the product documentations.

The following are outside the scope of this part of ISO/TS 13399: layer settings as defined in ISO/TS 13399-70; structure of the tool documentation as defined in ISO/TS 13399-71; applications where these standard data may be stored or referenced; concept of the classification of cutting tool data and their properties; concept of the design of 2D drawings for cutting tools; concept of the design of 3D models for cutting tools; application data for the use of those cutting tools; information about the reconditioning of cutting tools; information about additional application and usage data (e.g. coolant supply).
Cross References:
ISO 10303-28
ISO 5610-9
ISO 13399-1:2006
ISO/TS 13399-2
ISO/TS 13399-3
ISO/TS 13399-4
ISO/TS 13399-70
ISO/TS 13399-71


All current amendments available at time of purchase are included with the purchase of this document.

Product Details

Published: 07/31/2016 ISBN(s): 9780580910364 Number of Pages: 32 File Size: 1 file , 2.2 MB Same As: ISO/TS 13399-72:2016 Product Code(s): 30327455, 30327455, 30327455
