Full Description

Range of nominal shank dimensions for pull and tail ends of internal broaches for use on broaching machines, vertical type, and dimensions for locating the pull chuck in the pull block. Gives constant dimensions between the top of the pull block and the platen surface. Particularly applies to automatic handling of broaching tools.

Cross References:
BS 4500
BS 4656

Product Details

Published: 04/30/1976 ISBN(s): 0580090957 Number of Pages: 4 File Size: 1 file , 400 KB Product Code(s): 00068714, 00068714, 00068714
