Full Description

Capacitance range: up to 100 000 pF in E24 series (BS 2488). Selection tolerances: for $iC$dR 100 pF: 0.5 per cent, 1 per cent, 2 per cent, 5 per cent; for $iC$dR< 100 pF: 0.5 pF, 1 pF, 2 pF, 5 pF. Climatic categories: 55/100/A4; 55/100/21; 55/100/56. Rated temperature: 70 C. Temperature coefficient: for $iC$dR> 50 pF but 100 pF: -20 to +100 p.p.m./C; for $iC$dR> 100 pF: -20 to +150 p.p.m./C. A range of five case sizes and four rated voltages.

Cross References:
BS 2488
BS 9000
BS 9070:Sections 1

Product Details

Published: 02/15/1971 ISBN(s): 0580064972 Number of Pages: 14 File Size: 1 file , 410 KB Product Code(s): 00143862, 00143862, 00143862
