Full Description

Covers gears having modules of 1 mm and less including first and second preferences. Two basic racks (one with backlash allowance); modification of addendum and centre distance to suit various conditions. Four grades of accuracy with elemental and dual flank composite test tolerances. Appendices give information on single flank testing, calculation of measuring pin dimensions and examples of calculations for various design conditions. Metric equivalent of BS 978-1.

Cross References:
BS 308
BS 978:Part 1
BS 978:Part 2
BS 2519
BS 4500

Product Details

Published: 03/27/1970 ISBN(s): 058005988X Number of Pages: 29 File Size: 1 file , 2.4 MB Product Code(s): 00069157, 00069157, 00069157
