GMW16189

Description / Abstract: GMW16189, 3rd Edition, March 2020 - Sealings in Turbo Charger Applications

Note: Nothing in this standard supercedes applicable laws and regulations.

Note: In the event of conflict between the English and domestic language, the English language shall take precedence.

Purpose/Material Description.

This specification covers the materials of elastomeric sealings in turbocharger applications. Materials covered by this standard are divided into the following types:

Type A.

Ethylene Acrylate Elastomer (AEM) gasket for use in quick-connects for 160 °C permanent and 185 °C peak temperatures.

Type B.

Fluoroelastomer (FKM) gasket for use in quick-connects for 200 °C permanent and 225 °C peak temperatures.

Type C.

FKM sealings for static applications for 200 °C permanent and 225 °C peak temperatures.

Type D.

Silicone Elastomer (VMQ) sealings for static applications for 200 °C permanent and 225 °C peak temperatures.

Type E.

Drawing defined (e.g., using SAE J200 or ASTM D2000 line callout). If no type of material is indicated, material of Type A is sufficient.

Type F.

Ethylene Acrylate Elastomer (AEM) gasket for use in quick-connects for 135 °C permanent and 150 °C peak temperatures.

Type G.

Fluoroelastomer (FKM) gasket for use in quick-connects for 150 °C permanent and 175 °C peak temperatures.

Symbols.

Not applicable.

Applicability.

What is this standard used for? Be specific. Describe component, subsystem, system, vehicle or program. Do not indicate “Not applicable”.

Remarks.

None.
