Full Description

This sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors of type 9,52. It describes the interface dimensions for general purpose grade 2 connectors, dimensional details for standard test connectors, grade 0, together with gauging information and the mandatory tests selected from IEC 61169-1, applicable to all DS relating to type 9,52 connectors. The main change introduced in this edition is that the maximum frequency is now 3 GHZ.

Product Details

Edition: 2.0 Published: 02/16/2007 Number of Pages: 20 File Size: 1 file , 180 KB
