Full Description

IEC 62453-301:2009(E) provides information for integrating the FOUNDATION^TM Fieldbus (FF) protocol into the FDT standard (IEC 62453-2). It describes communication definitions, protocol specific extensions and the means for block (e.g. transducer, resource or function blocks) representation. The new protocol specific definitions are based on FF-specifications for H1 and HSE protocols. Furthermore, the definitions contain information that is needed by systems to configure FF devices. Communication Profile Family 1 (commonly known as FOUNDATION^TM Fieldbus) defines communication profiles based on IEC 61158-2, Type 1, IEC 61158-3-1, IEC 61158-4-1, IEC 61158-5-5, IEC 61158-5-9, IEC 61158-6-5, and IEC 61158-6-9. The basic profiles CP 1/1 (FF H1) and CP 1/2 (FF HSE) are defined in IEC 61784-1.

This publication is to be read in conjunction with IEC 62453-2:2009.

Product Details

Edition: 1.0 Published: 06/30/2009 Number of Pages: 128 File Size: 1 file , 2.1 MB
