Full Description

STIL language constructs are defined to specify the DC conditions necessary to excute digital vectors on automated test equipment(ATE). STIL language extensions include structures for:(a) specifying the DC conditions for a device under test; specifying DC conditions either globally, by pattern burst, by pattern, or by vector;(c) specifying alternate DC levels;and (d) selecting DC levels and alternate levels within a period, much the same as timed format events.

Product Details

Edition: 1.0 Published: 11/07/2007 Number of Pages: 39 File Size: 1 file , 1 MB
