Full Description

The test method is applicable to leadless surface mounting components and surface mounting connectors to which pull test is not applicable. It is not applicable to multi-lead components and gull-wing leads. The method is designed to test and evaluate the endurance of the solder joint between component terminals and lands on a substrate, by means of a shear type mechanical stress. This test is applicable to evaluate the effects of repeated temperature change on the strength of the solder joints between terminals and lands on a substrate.

Product Details

Edition: 1.0 Published: 07/25/2007 Number of Pages: 17 File Size: 1 file , 290 KB
