Full Description

Is applicable to variable capacitors, potentiometers and variable resistors for use in electronic equipment.The dimensions have been selected from IEC 60390 and IEC 60620 because the ranges of dimensions were considered too large and contained too many variants for capacitors and resistors for electronic equipment. It contains preferred dimensions for shaft ends and bushes and for the mounting of single-hole, bush-mounted, shaft-operated variable capacitors, variable resistors and potentiometers. If other dimensions not listed have to be used, it is recommended to select them also from the above-mentioned standards. The contents of the corrigendum of February 2008 have been included in this copy.

Product Details

Edition: 2.0 Published: 11/28/2006 Number of Pages: 15 File Size: 1 file , 340 KB
