Full Description

Scope

This standard defines terms pertaining to transitions, pulses, and related waveforms and defines procedures for estimating their parameters.

Purpose

The purpose of the standard is to unambiguously and accurately define terms pertaining to transitions, pulses, and related waveforms and the algorithm for their computation. This helps to communicaterequirements between vendors and users, improves understanding and readability of instrument performance specifications, and provides a common ground for parameter and performance comparisons.

Abstract

Revision Standard - Active.Approximately 100 terms and their definitions, for accurately and precisely describing the waveforms of pulse signals and the process of measuring pulse signals, are presented in this standard. Algorithms are provided for computing the values of defined terms that describe measurable parameters of the waveform, such as transition duration, state level, pulse amplitude, and waveform aberrations. These analysis algorithms are applicable to two-state waveforms havingone or two transitions connecting these states. Compound waveform analysis is accomplished by decomposing the compound waveform into its constituent two-state single-transition waveforms.

Product Details

Published: 09/06/2011 ISBN(s): 9780738180915, 9780738180922, 9780738167060, 9780738167077, 9781504413381 Number of Pages: 71 File Size: 1 file , 830 KB Redline File Size: 2 files , 2.1 MB Product Code(s): STD97138, STDRL97138, STDPD97138, STDPDRL97138, STDPL97138
