Full Description

Scope

This standard applies to premium-efficiency totally enclosed fan-cooled (TEFC), horizontal and vertical, single-speed, squirrel cage polyphase induction motors, up to and including 370 kW (500 hp), and 4000 V nominal, in National Electrical Manufacturers Association (NEMA) frame sizes 143T and larger, for petroleum, chemical, and other severe-duty applications (commonly referred to as premium-efficiency severe-duty motors). Excluded from the scope of this standard are motors with sleeve bearings and additional specific features required for explosion-proof motors.

Purpose

The purpose of this standard is to define a specification that deals with mechanical and electrical performance, electrical insulation systems, corrosion protection, and electrical and mechanical testing for severe-duty TEFC squirrel cage polyphase induction motors, up to and including 370 kW (500 hp), for petroleum and chemical industry application. Many of the specified materials and components in thisstandard stem from experience with severely corrosive atmospheres and the necessity for safe, quiet, reliable, premium efficiency motors.

Abstract

Revision Standard - Active.This standard applies to premium efficiency totally enclosed fan-cooled (TEFC), horizontal and vertical, single-speed, squirrel cage polyphase induction motors, up to and including 370 kW (500 hp), and 4000 volts in National Electrical Manufacturers Association (NEMA) frame sizes 143T and larger, for petroleum, chemical, and other severe duty applications (commonly referred to as premium efficiency severe duty motors). Excluded from the scope of this standard are motors with sleeve bearings and additional specific features required for explosion-proof motors.

Product Details

Published: 08/17/2009 ISBN(s): 9780738159249, 9780738159232, 9780738168883, 9780738168876, 9781504411608 Number of Pages: 25 File Size: 1 file , 320 KB Redline File Size: 4 files , 4.7 MB Product Code(s): STDRL95916, STD95916, STDPD95916, STDPDRL95916, STDPL95916
