Full Description

Scope

This standard establishes specifications for high-voltage (above 1000 V) distribution and power class expulsion, current-limiting, and combination-type external capacitor fuses and accessories, with rated voltages from 1 kV through 38 kV, for protecting shunt capacitors complying with IEEE Std 18?-20021 and NEMA CP 1-2000. All of these devices are intended for use on ac systems. These fuses may be used with capacitor units, groups of units, or entire banks and include specific capacitor line [group] and capacitor unit fuse types as follows:a) Current-limiting fusesb) Expulsion fusesc) Combination of current-limiting and expulsion fusesd) Fuse supports, fuse mountings, and accessories used with fuses of type a), type b), and type c)e) Current-limiting, expulsion, and combination-type capacitor fuses [type a), type b), and type C), respectively] used in fuse enclosure packages (FEPs)

Abstract

New IEEE Standard - Superseded.This standard establishes specifications for high-voltage (above 1000 V) distribution and power class expulsion, current-limiting, and combination-type external capacitor fuses and accessories, with rated voltages from 1 kV through 38 kV, for protecting shunt capacitors complying with IEEE Std 18-2002 and NEMA CP 1-2000. All of these devices are intended for use on ac systems. These fuses may be used with capacitor units, groups of units, or entire banks and include specific capacitor line [group] and capacitor unit fuse types as follows: a) Current-limiting fuses; b) Expulsion fuses; c) Combination of current-limiting and expulsion fuses; d) Fuse supports, fuse mountings, and accessories used with fuses of type a), type b), and type c); and e) Current-limiting, expulsion, and combination-type capacitor fuses [type a), type b), and type c), respectively] used in fuse enclosure packages (FEPs). (Superseded by IEEE C37.42-2016.)

Product Details

Published: 07/25/2008 ISBN(s): 9780738157818, 9780738157801 Number of Pages: 22 File Size: 1 file , 350 KB Product Code(s): STDSU95812
