Full Description

Scope

This guide provides maintenance testing and failure analysis guidance for form-wound, squirrel cage, induction machinery rated up to 15 kV. The guide addresses the following machine systems:¿¿¿ Stator (winding and wore)¿¿¿ Rotor (winding and core)¿¿¿ Vibration and noise¿¿¿ Bearings and shafts¿¿¿ Structure, frame¿¿¿ Ventilation¿¿¿ Accessories

Purpose

This document is intended for the following purposes:¿¿¿ To provide guidance concerning the appropriateness of various maintenance tests and interpreting the results of those tests with respect to failure analysis and to routine predictive maintenance activities¿¿¿ To provide a methodology by which the most probable cause of any particular machine failure may bedetermined¿¿¿ To encourage the establishment of routine and uniform data collection so valuable facts of the failure are not destroyed¿¿¿ To facilitate cooperative efforts by users and manufacturers during failure analysis

Abstract

Revision Standard - Active.This guide provides maintenance testing and failure analysis guidance for form-wound, squirrel cage, induction machinery rated up to 15 kV. It addresses the following machine systems: Stator (Winding and Core) Rotor (Winding and Core) Vibration and Noise Bearings and Shafts Structure, Frame Ventilation Accessories. This guide is intended for use by personnel at the facility or corporate office responsible for the operation and maintenance of large induction machines. It is a guide to aid the thought processes and procedures necessary to determine root causes for failures.

Product Details

Published: 04/30/2007 ISBN(s): 9780738155647, 9781504410274, 9780738155654 Number of Pages: 68 File Size: 1 file , 580 KB Product Code(s): STD95671, STDPD95671, STDPL95671
