Full Description

Scope

Procedures and test voltage values for acceptance and maintenance testing of ESP cable systems are presented. This procedure applies to cable systems rated 3 kV and 5 kV (phase to phase).

Purpose

The purpose of this recommended practice is as follows:a) Provide a guideline for performing leakage current so it can be used as a cable quality toolb) Provide guidelines for evaluation of the test resultsc) Define terms that have a specific meaning to the recommended practice

Abstract

Revision Standard - Superseded.Procedures and test voltage values for acceptance and maintenance testing of electrical submersible pump (ESP) cable systems are presented. This recommended practice applies to cable systems rated 3 kV and 5 kV (phase to phase) and is intended only for this special-purpose cable. The intent is to provide uniform test procedures and guidelines for evaluation of the test results.

Product Details

Published: 04/13/2005 ISBN(s): 0738140775, 9780738140773, 9780738140780 Number of Pages: 26 File Size: 1 file , 800 KB Product Code(s): STDSU95250, STDPD95250
