Full Description

Scope

Specification and test requirements for a single-axis Coriolis vibratory gyro (CVG) for use as a sensor in attitude control systems, angular displacement measuring systems, and angular rate measuring systems are defined. A stadard specification format guide for the preparation of a single-axis CVG is provided. A complilation of recommended procedures for testing a CVG, derived from those presently used in the industry, is also provided. Informative annexes cover CVG design features and theoretical principles of operation.

Purpose

This standard is provided as a guide for the preparation of Coriolis vibratory gyro (CVG) specification and test procedures. The CVG is a device which measures inertial angular rate through the Coriolis force produced from a vibrating mass in a non-inertial reference frame. This gyro type encompasses low cost Micro-Electro-Mechanical-Systems (MEMS) devices on silicon or quartz chips and also inertial navigation grade vibrating shell gyros.

Abstract

New IEEE Standard - Active.Specification and test requirements for a single-axis Coriolis vibratory gyro (CVG) for use as a sensor in attitude control systems, angular displacement measuring systems, and angular rate measuring systems are defined. A standard specification format guide for the preparation of a single-axis CVG is provided. A compilation of recommended procedures for testing a CVG, derived from those presently used in the industry, is also provided. Informative annexes cover CVG design features and theoretical principles of operation.

Product Details

Published: 12/20/2004 ISBN(s): 0738140058, 9780738140063, 9780738140056, 9781504409391 Number of Pages: 78 File Size: 1 file , 980 KB Product Code(s): STD95224, STDPD95224, STDPL95224
