Full Description

Scope

Outdoor and indoor power apparatus bushings of condenser type which have basic impulse insulation levels of 110 kv and above for use a scompionents of oil-filled converter transformers and smoothing reactors as well as wall bushings.

Purpose

Define special terms used, service conditions, ratings, general requirements, electrical insulation characteristics and test procedures for bushings for DC application.

Abstract

New IEEE Standard - Superseded.This standard applies to outdoor and indoor power apparatus dc bushings of condenser type that have basic impulse insulation levels of 110 kV and above for use as components of oil-filled converter transformers and smoothing reactors, as well as air-to-air dc bushings. This standard defines the special terms used, service conditions, rating, general requirements, electrical insulation characteristics, and test procedure for the bushings for dc application.

Product Details

Published: 11/30/1996 ISBN(s): 9780738111247, 9781504419550 Number of Pages: 32 File Size: 1 file , 290 KB Product Code(s): STDSU94457, STDPL94457
