Full Description

Scope

Guidance on the use of outdoor power apparatus bushings is provided in this document. The bushings arelimited to those built in accordance with IEEE Std C57.19.00-1991.

Purpose

The purpose of this guide is to present general information and recommendations for the application of power apparatus bushings when incorporated as part of power transformers, power circuit breakers, and isolated-phase bus. The loading model developed in this guide is based on oil-impregnated, paper-insulated, capacitance-graded bushings. Similar loading models could be developed for other bushing constructions.

Abstract

New IEEE Standard - Superseded.Guidance on the use of outdoor power apparatus bushings is provided. The bushings are limited to those built in accordance with IEEE Std C57.19.00-1991. General information and recommendations for the application of power apparatus bushings, when incorporated as part of power transformers, power circuit breakers, and isolated-phase bus, are provided.

Product Details

Published: 12/01/1995 ISBN(s): 9780738108810 Number of Pages: 32 File Size: 1 file , 370 KB Product Code(s): STDSU94302
