Full Description

Scope

This standard establishes the design requirements for a military module, format E form factor. The requirements herein serve to specify the mechanical design of the module. This standard is designed for use in conjunction with other IEEE standards.

Purpose

The purpose of this standard is the specification of dimensions and tolerances that will ensure the mechanical intermateability of military modules within associated subracks. In addition, mechanical characteristics for military applications are also included. This standard covers the basic dimensions, frames, PWBs, materials, assembly, and chassis interface of single-sided and double-sided military modules.

Abstract

New IEEE Standard - Inactive-Withdrawn.Withdrawn Standard. Withdrawn Date: Jan 15, 2001. No longer endorsed by the IEEE. The mechanical design requirements for a military module, format E form factor are established. The specificaitons of dimensions and tolerances are intended to ensure the mechanical intermateability of military modules within associated subracks. Mechanical characteristics for military applications are also included.

Product Details

Published: 08/26/1993 ISBN(s): 1559373490, 9780738127583 Number of Pages: 28 File Size: 1 file , 280 KB Product Code(s): STDWD16618
