Full Description

Scope

This is a detail standard for subracks, plug-in-units, printed boards, and backplanes to be used in conjunction with IEEE Std 1301-19911 and a 2.5 mm connector in accordance with IEC 48B (Central Office) 245.

Purpose

This standard is an implementation of IEEE Std 1301-1991. This standard may be used with other IEEE Std 1301.x connector implementations in the same subrack.

Abstract

New IEEE Standard - Inactive-Reserved.Recommendations provide guidance in the implementation of the generic standard, IEEE Std 1301-1991, and the connector-related standards, such as IEEE Std 1301.1-1991 and IEEE Std 1301.3-1992. This recommended practice may be applied in all fields of electronics where equipment and installations are required to conform to a metric modular order. The IEEE 1301 metric equipment practices are in accordance with IEC 917 (1988) and IEC 917-0 (1989), including cabinet, rack, subracks, printed boards, and common connector-dependent dimensions for connector pitches of 2.5, 2.0, 1.5, 1.0, and 0.5 mm.

Product Details

Published: 11/30/1992 ISBN(s): 9780738112008 Number of Pages: 20 File Size: 1 file , 500 KB Product Code(s): STDRES15875
