Full Description

Scope

This standard is intended for use as a basis for determining performance, interchangeability, and safety of the equipment covered, and to assist in the proper selection of such equipment.

Abstract

New IEEE Standard - Inactive-Withdrawn.This standard covers certain electrical, dimensional, and mechanical characteristics and takes into consideration certain safety features of single-phase, 60 Hz, mineral-oil-immersed, self-cooled, padmounted, compartmental-type distribution transformers with high-voltage bushings. These transformers are rated 167 kVA and smaller, with high-voltages of 34500 GRD/19900 volts and below for operation between one phase and grounded neutral, and low-voltage of 240/120 volts. These transformers are generally used for step-down purposes from an underground primary cable supply.NOTE¿¿¿Refer to latest federal regulations concerning polychlorinated biphenyl (PCB) contaminations in transformers.

Product Details

Published: 12/31/1992 ISBN(s): 9780738136257 Number of Pages: 18 File Size: 1 file , 110 KB Product Code(s): STDWD95108
