Full Description

Scope

The scope of this standard includes enclosed low-voltage ac power circuit breakers, as follows:1) Stationary or draw-out type of two- or three-pole construction, with one or more rated maximum voltages of 635 V (600 V for units incorporating fuses), 508 V, and 254 V for application on systems having nominal voltages of 600 V, 480 V, and 240 V.2) Unfused or fused type;3) Manually operated or power operated, with or without electromechanical or solid-state trip devices.

Abstract

Revision Standard - Superseded.This standard covers enclosed low-voltage AC power circuit breakers of the stationary or draw-out type of two- or three-pole construction, with one or more rated maximum voltages of 635 V (600 V for units incorporating fuses), 508 V, and 254 V for application on systems having nominal voltages of 600 V, 480 V, and 240 V; with unfused or fused circuit breakers; manually or power operated; and with or without electromechanical or solid-state trip devices. It deals with service conditions, ratings, functional components, temperature limitations and classifications of insulating materials, insulation (dielectric) withstand voltage requirements, test procedures, and application.

Product Details

Published: 05/21/1991 ISBN(s): 9780738110509 Number of Pages: 19 File Size: 1 file , 69 KB Product Code(s): STD14241, STDSU14241
