Full Description

Scope

2.1 This guide defines thermal limit curves, recommends a standard procedure for construction of the curves, and provides the definitions and information necessary to properly use these curves.2.2 The guide also describes thermal limit curves for large squirrel-cage motors defined as those motor ratings built in frames larger than the frame normally used for 500 hp, 1800 r/min motors.

Purpose

The purpose of this guide is to assist in a uniform understanding of the construction, interpretation, and use of motor thermal limit curves.

Abstract

New IEEE Standard - Inactive-Withdrawn.Thermal limit curves for induction machines are defined. A procedure is established for the presentation of these curves, and guidance for the interpretation and use of these curves for machine thermal protection is provided.

Product Details

Published: 03/09/1987 ISBN(s): 9780738143910 Number of Pages: 8 File Size: 1 file , 140 KB Product Code(s): STDWD11007
