Full Description

Scope

This standard applies to outdoor series capacitor banks and to the major components of a bank that are required to form a complete system for the insertion of capacitors in series with a transmission line. These major components include capacitors, varistors, bypass gaps, bypass switches, discharge current limiting reactors, insulated structures, and protection and control systems. This standard defines the major requirements for the bank and these components. Design and production tests for all of the components are outlined. Disconnect switches associated with the series capacitor bank are not discussed in detail.This standard applies to fixed series capacitor banks where the inserted reactance is primarily established bythe reactance of the capacitors. Not included in this standard are power electronic devices for the insertion orbypassing of the bank. In addition, series capacitor banks applied to distribution circuits are not within thescope of this standard.

Purpose

The purpose of this standard is to provide the basis for design of fixed series capacitor banks. The standard will discuss all available technologies and the basis for ratings.

Abstract

Revision Standard - Withdrawn - Draft.

Product Details

Number of Pages: 62
