Full Description

Scope

This standard covers certain electrical, dimensional, and mechanical characteristics and takes into consideration certain safety features of three-phase, 60-Hz, liquid-immersed, self-cooled, network transformers with a primary grounding switch. These transformers are rated 2500 kVA and below with high voltages of 34 500 volts and below and secondaries of 600 volts and below. These transformers are generally used for step-down purposes from underground primary cables and supply a secondary network system through network protectors. These transformers are typically installed below ground level.

Purpose

This standard is intended for use as a basis for establishing the performance, electrical and mechanical interchangeability, safety of the equipment covered, and to assist in the proper selection of such equipment.

Abstract

Revision Standard - Active.This standard is intended for use as a basis for establishing the performance, interchangeability, and safety of the equipment covered and to assist in the proper selection of such equipment.

Product Details

Published: 08/31/2017 ISBN(s): 9781504441124, 9781504441131, 9781504443630 Number of Pages: 33 File Size: 1 file , 3.1 MB Product Code(s): STD22639, STDPD22639, STDPL22639
