Full Description

Scope

This standard defines DATPG output data formats and informational content for UUT models, stimulus and response patterns, fault dictionaries, and diagnostic probing. These outputs provide a standard exchange format to automatic test equipment (ATE).

Purpose

This standard is to be used as the standard definition of DATPG output formats and informational content.

Abstract

Revision Standard - Active.The information content and the data formats for the interchange of digital test program data between digital automated test program generators (DATPGs) and automatic test equipment (ATE) for board-level printed circuit assemblies are defined. This information can be broadly grouped into data that defines the following: user under test (UUT) model, stimulus and response, fault dictionary, and probe.

Product Details

Published: 01/27/2017 ISBN(s): 9781504436915, 9781504436922, 9781504437776 Number of Pages: 64 File Size: 1 file , 1 MB Product Code(s): STD22392, STDPD22392, STDPL22392
