ISO 15031-6:2015

ISO 15031-6:2015 Road vehicles - Communication between vehicle and external equipment for emissions-related diagnostics - Part 6: Diagnostic trouble code definitions

standard by International Organization for Standardization, 08/01/2015

More details

Reduced price!

M00045397

New product

Limited time offer:

$46.35

$103.00

-55%

In stock

- +

Add to compare

More info
Custom tab

More info

Full Description

ISO 15031-6:2015 provides uniformity for standardized diagnostic trouble codes (DTC) that electrical/electronic On-Board Diagnostic (OBD) systems of motor vehicles are required to report when malfunctions are detected. It further provides guidance for uniform messages (text descriptor) associated with these codes.

ISO 15031-6:2015 specifies the rules and guidelines for the definition of the following: a) the diagnostic trouble code format, which consists of addressing format, structure and messages; b) a description of the standardized set of diagnostic trouble codes and descriptions contained in SAE J2012-DA. The two most significant bytes of a DTC may be decoded according to two different lists in two formats: DTC Format Identifier 00₁₆ and 04₁₆; and c) a description of the standardized set of diagnostic trouble codes subtypes known as failure types contained in SAE J2012-DA (applies only when 3-byte DTCs are used).

ISO 15031-6:2015 specifies all general rules and guidelines to define new diagnostic trouble codes. It references SAE J2012-DA (Digital Annex), which includes all standardized DTCs (number and text descriptor) as well as all diagnostic trouble codes subtypes known as failure types.
