Full Description

ISO 10303-113:2020 specifies the integrated resource constructs for Mechanical features.

The following are within the scope of this document:

constraints on life cycle context invariant identifiers for topological items; counterbore, countersink, counterdrill, and spotface description and application; features that are to be manufactured by either milling or turning processes; features that can be replicated in patterns; generic mechanical design concepts; implicit representation of machining features through selection of standard parameters; machining feature definition elements necessary for creating machining features; machining features for defining shapes necessary for manufacturing; product and manufacturing information placeholder in a three dimensional geometric model; shape representations necessary for creating machining features.

Product Details

Published: 10/01/2020 File Size: 1 file , 2.2 MB
