Full Description

This International Standard specifies the dimensions and tolerances, in millimetres, of ejector pins with cylindrical head which are used in compression and injection moulds and in die casting dies.

It also gives material guidelines and hardness requirements, and specifies the designation of ejector pins with cylindrical head.

Flat ejector pins are specified in ISO 8693, shouldered ejector pins are specified in ISO 8694.
