Full Description

This International Standard gives the boundary dimensions and other relevant dimensions of accessories for rolling bearings, linear motion, recirculating ball, sleeve type - metric series. The essential dimensions for housings, shaft support rails and shaft support blocks are given and generally without tolerance. This standard was developed to be used with International Standard ISO 10285.

This standard includes the following accessories:

Housings:

flangeless, closed and adjustable types for series 1flanged, closed and adjustable types for series 3flanged, open type for series 3flangeless, closed and adjustable types for series 3flangeless, open and open adjustable types for series 3Shaft support railsShaft support rails, low height typeShaft support blocks, flanged typeShaft support blocks, flangeless typeShafts, Solid and tubular for linear motion rolling bearings

Product Details

Published: 04/01/1998 Number of Pages: 18 File Size: 1 file , 230 KB
