ISO 9199:1998
ISO 9199:1998 Aerospace - Nuts, bihexagonal, self-locking, MJ threads, classifications: 1 100 MPa (at ambient temperature)/425 degrees C, 1 100 MPa (at ambient temperature)/650 degrees C, 1 210 MPa (at ambient temperature)/425 degrees C, 1 210 MPa (at ambient temperature)/730 degrees C, 1 550 MPa (at ambient temp
standard by International Organization for Standardization, 03/01/1998
Full Description
This International Standard specifies the dimensions of bihexagonal nuts with counterbore and MJ threads and a self-locking feature achieved by forming the upper portion out-of-round, for classifications: 1100 MPa1)/425 C2), 1100 MPa1)/650 C2), 1210 MPa1)/425 C2), 1210 MPa1)/730 C2), 1550 MPa1)/235 C2), 1550 MPa1)/425 C2)and 1550 MPa1)/600 C2).
This International Standard is only applicable for the compilation of aerospace product standards.
1) Corresponds to the minimum tensile stress which the nut is able to withstand at ambient temperature without breaking or cracking when tested with a bolt of a higher strength class.
2) Maximum temperature that the nut is able to withstand, without permanent alteration to its original characteristics, after ambient temperature has been restored. The maximum temperature is conditioned by the material or by the surface treatment.
