Full Description

This international Standard specifies the characteristics of full-length parallel grooved pins made of steel or austenitic stainless steel with chamfer which have three equally spaced grooves impressed longitudinally on their exterior surface and a pilot to facilitate insertion, with nominal diameter, d₁, from 1,5 mm to 25 mm inclusive.

The displaced material to each side of the grooves forming an expanded diameter d₂ which is larger than the nominal diameter d₁ will cause a non-positive locking fit when these grooved pins are forced into a drilled hole equal to the nominal diameter d₁ (see clause 4).
