Full Description

Specifies maximum and minimum dimensions for these clamps installed by means of a bolt with a nominal diameter of 5 mm. The specified dimensions define a dimensional envelope. Shall not be considered as an interchangeability standard. The tolerances for each type of clamp are to be defined in the parts standards drawings.
