Full Description

Specifies dimensional requirements necessary for the mounting of injection nozzle holders in diesel engines. The location of the fuel inlet and leak-off connections are not defined since they vary according to the particular application. A figure illustrates the shape and reference quantities of concern. Preferred shank lengths are given in table 2.
