Full Description

Specifies the envelope dimensions of axial type nipples and determines the clearance space which shall be provided in the region of the nipple to allow the lubricating gun to be connected, and the operating angle dimensions for the lubricating process. The tip design of the nipples is optional provided the profile remains within the envelope shown in figure 1.
