Full Description

ISO 14405-3:2016 establishes the default specification operator for angular size and defines a number of special specification operators for features of angular size: cone (truncated, i.e. frustum, or not), wedge (truncated or not), two opposite straight lines (intersection of a wedge/truncated wedge and a plane perpendicular to the intersection straight line of the two planes of the wedge/truncated wedge, intersection of a cone/frustum and a plane containing the axis of revolution of the cone/frustum). See Figure 1 and Figure 2.

ISO 14405-3:2016 also defines the specification modifiers and the drawing indications for these angular sizes.

ISO 14405-3:2016 covers the following angular sizes:

- local angular size:

- angular size between two lines;- portion angular size;

- global angular size:

- direct global angular size:- least squares angular size;- minimax angular size;- rank order angular size/indirect global angular size:- maximum angular size;- minimum angular size;- average angular size;- range of angular sizes;- mid-range angular size;- median angular size;- standard deviation of angular size.

ISO 14405-3:2016 defines the meaning of tolerances of angular sizes indicated as

- + and/or - limit deviations, e.g. 0°/-0,5°, or

- indicated with upper limit of size (ULS) and/or lower limit of size (LLS), e.g. 35° max. or 15° min., 34°/36°,

- with or without modifiers.

ISO 14405-3:2016 provides a set of tools to express several types of angular size characteristics. It does not give any information on the relationship between a function or a use and an angular size characteristic.

Product Details

Published: 12/15/2016 Number of Pages: 30 File Size: 1 file , 1.8 MB Same As: DIN EN ISO 14405-3, BS EN ISO 14405-3:2017
