Full Description

This International Standard specifies the characteristics of normal-series, product-grade-C plain washers in the 100 HV hardness class and of nominal sizes (nominal thread diameters) ranging from 1,6 mm to 64 mm inclusive.

Washers of hardness class 100 HV are suitable for

hexagon bolts and screws of product grade C in property classes up to and including 6.8;hexagon nuts of product grade C in property classes up to and including 6;case-hardened thread rolling screws.

If dimensions other than those listed in this International Standard are required, they should be selected from those given in ISO 887.

When soft material pieces are clamped, or large clearance holes in the workpiece are used, the user should check the technical suitability of this type of washer.

Product Details

Published: 06/01/2000 Number of Pages: 4 File Size: 1 file , 41 KB Same As: BS EN ISO 7091:2000, BS EN ISO 7091:2000
