Full Description

This Practice provides fabricators with standard details for circular platforms for vertical vessels. This Practice describes the requirements and the design details for fabrication of circular vessel platforms including ladders and railing. PIP STE05535, Vessel Circular Platform Detail Guidelines, a guide for use by engineers who are providing the circular platforms in accordance with this Practice and for use by engineers who are designing the vessels to support these vessel platforms, is available on the PIP web site or from the PIP office. PIP STE05535 provides information to engineers about the design basis of the platforms, circumstances that should be considered before using this Practice, and a table showing the platform design loads for the vessel clips. Table 1 in PIP STE05535 should be used to check whether the vessel requires reinforcement to receive the platform loads.

Product Details

Published: 03/01/2005 File Size: 1 file , 430 KB
