Full Description

This SAE Standard is equivalent to ISO Standard 6626. This document specifies the essential dimensions of piston ring types DSF-C, DSF-CNP, SSF, GSF, DSF-NG, and SSF-L coil spring loaded oil control rings

For the cast iron part the recommended material is class 10 according to SAE J1590. For special applications material classes 20 to 50 may be used.

Variation in face design and spring groove from these may be used, as recommended by individual manufacturers, in plain or chromes versions.

The tangential forces of coil spring loaded oil control rings can be varied over a wide range. Explanations and recommendations are given.

The normal range for axial width of coil spring loaded oil control rings (3 to 8 mm inclusive) is divided into 0.5 or 1.0 mm steps.

This document applies to coil spring loaded oil control rings up to 200 mm inclusive for reciprocating internal combustion engines. It may also be used for piston rings of compressors working under similar conditions.

Product Details

Published: 06/30/2008 File Size: 1 file , 3.1 MB
