Full Description

This SAE Standard covers two types of hose fabricated from textile reinforcement and synthetic rubber, assembled with end fittings for use in high-temperature automotive power steering applications as flexible connections within the temperature range of -40 to +150 degrees C (-40 to +302 degrees F) maximum and 10.3 MPa (1500 psi) maximum working pressure. These hoses are intended for use in applications where reduction in amplitude of pump pressure pulsations is required. Class A hose has a nominal OD of 19.84 mm (0.781 in). Class B hose is a lightweight hose with a nominal OD of 17.91 mm (0.705 in). This specification defines the minimum performance levels of a flexible connector in the hydraulic steering system to convey power steering fluid from the steering pump to the steering gear.

Product Details

Published: 04/01/2001 File Size: 1 file , 28 KB
